Name: XCSA702EX Telemecanique | Industify
Brand: Telemecanique
SKU: XCSA702EX
Price: 1.00 USD
Availability: InStock

Product or component type

Safety switch

Device short name

XCSA

material

Metal

Head type

Key operated turret head

Electrical connection

Terminal

Clamping connection capacity

1 x 0.5…2 x 1.5 mm² with or without cable end

Contacts type and composition

2 NC + 1 NO

Contact operation

break before make, Slow-break

Positive opening

With NC contact

Locking options description

Without locking of actuator

Local signalling

Without

Contact code designation

A300, AC-15 (Ue = 120 V, AC-15 (Ue = 240 V, DC-13 (Ue = 125 V, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1, Ie = 0.55 A) conforming to EN/IEC 60947-5-1, Ie = 3 A) conforming to EN/IEC 60947-5-1, Ie = 6 A) conforming to EN/IEC 60947-5-1, Q300

Actuator force for extraction

20.0000 NEWTON

Operating rate

10 cyc/mn for maximum durability

Body Material

Zamak

Head material

Zamak

Safety level

can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508, Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1

Safety reliability data

B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear

Protective treatment

Vibration resistance

5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6

Shock resistance

10 gn for 11 ms conforming to IEC 60068-2-27

Electrical shock protection class

Class I conforming to EN/IEC 60536

IP degree of protection

IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1

Marking

II2 D-Ex tb IIIC T85°C Db IP67

Dust zone

Zone 21 – 22

Product certifications

IEC-Ex INE 17.0020X

Standards

EN/IEC 60079-0

Directives

2014/34/EU – ATEX directive

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

6.5000 CENTIMETER

Package 1 width

6.6000 CENTIMETER

Package 1 length

15.8000 CENTIMETER

Package 1 weight

544.0000 GRAM

Unit type of package 2

S02

Package 2 height

15.0000 CENTIMETER

Package 2 width

30.0000 CENTIMETER

Package 2 length

40.0000 CENTIMETER

Package 2 weight

5.7430 KILOGRAM

Brand

Telemecanique

Description

Telemecanique Safety Switch XCSA702EX for Enhanced Safety and Reliability

Ensure Safety and Peace of Mind: The Telemecanique Safety Switch XCSA702EX is designed to provide reliable safety measures in various industrial settings. With a positive opening contact operation and locking options, this device ensures that the actuator force is sufficient for extraction, offering top-notch safety levels and reliability data.

Robust Construction for Durability: Built with high-quality materials such as Zamak, this Safety Switch can withstand vibration, shock, and harsh environmental conditions. The protective treatment, along with its IP67 degree of protection, guarantees long-term usage and resistance to dust and water ingress.
