Name: 9013GSG2J23R Telemecanique | Industify
Brand: Telemecanique
SKU: 9013GSG2J23R
Price: 1.00 USD
Availability: InStock

Range of product

Pumptrol

Pressure sensor name

9013GS

Value of setting

40…20 psi

Electrical circuit type

Power circuit

Product specific application

Control electrically driven water pumps and air compressors

Quantity per set

Type of packing

Individual

Factory modification

Not applicable

Pressure sensor type

Electromechanical pressure switch

Controlled fluid

Air (32-158 °F), Fresh water (32-158 °F)

Pressure switch type of operation

Regulation between 2 thresholds

Pressure actuator

Diaphragm

Setting

Internal

Scale type

Adjustable differential

Local display

Without

Contacts type and composition

2 NO, DPST-DB, Form YY, snap action

Electrical connection

Screw-clamp terminals, clamping capacity: 10 AWG, clamping capacity: 5.261 mm²

Materials in contact with fluid

nitrile (Buna-N) or equivalent rubber diaphragm, Zinc plated steel or equivalent flange

Fluid connection type

0.25 inch NPSF internal conforming to UL 508

material

noryl thermoplastic resin or equivalent: cover, Polypropylene: cover

Operating position

Any position

Terminal block type

4 terminals

Operating rate

10.0000 CYCLE_PER_MINUTE

Repeat accuracy

+/- 3 %

Terminals description ISO n°1

L1-T1

Standards

NSF ANSI 372

Product certifications

UL listed

Protective treatment

None

NEMA degree of protection

NEMA 1 conforming to UL 50

IP degree of protection

IP20 conforming to IEC 60529

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

25.8060 CENTIMETER

Package 1 width

10.1600 CENTIMETER

Package 1 length

65.5480 CENTIMETER

Package 1 weight

870.8970 GRAM

Brand

Telemecanique

Description

Telemecanique Pumptrol Pressure Switch

The Telemecanique Pumptrol Pressure Switch offers reliable control for electrically driven water pumps and air compressors, ensuring optimal performance and system efficiency. With a range of 40-20 psi, this electromechanical pressure switch regulates pressure between two thresholds, providing precise control over fluid operations.

Adjustable Differential: Allows for custom settings based on specific application needs.
Durable Materials: Constructed with high-quality materials to withstand diverse fluid environments.
User-Friendly Design: Featuring a local display and easy-to-use terminals for straightforward installation and operation.

Designed for versatility and reliability, the Telemecanique Pumptrol Pressure Switch meets industry standards and certifications while offering a protective NEMA 1 rating and IP20 degree of protection. Enhance your system’s performance and efficiency with this precision pressure switch.
