HomeShopPressure SensorsGauge Pressure SensorsZMLPA1P2SW Telemecanique
Telemecanique ZMLPA1P2SW OsiSense XMElectronic pressure sensors - industify.com
Telemecanique

ZMLPA1P2SW Telemecanique

SKU: ZMLPA1P2SW

Add to wishlist Add to compare
Categories: , , , , Tag:
Product information
Range of product

OsiSense XM
Product or component type

Electronic pressure sensors
Device short name

ZMLP
Display range

-14.5…6000
[Us] rated supply voltage

24 V DC SELV (voltage limits: 17-33 V)
Current consumption

= 50 mA
Electrical connection

2 pins, 4 pins, Female connector M12, Male connector M12
Type of output signal

Analogue + discrete
Analogue output function

4…20 mA
Discrete output type

NO/NC programmable, Solid state PNP
Switching function

Window
Voltage drop

2.0000 VOLT
Marking

CE
Front material

Polyester
Housing material

PBT Valox
Operating position

Any position
Protection type

Reverse polarity
Response time on output

= 3 ms for analog output, = 3 ms for discrete output
Display Type

4 digits 7 segments
Local signalling

1 LED (yellow) for light ON when switch is actuated
Response Time

300 ms
Delay first up

100.0000 MILLISECOND
Accuracy

= – 0.1 % of the measuring range
Measurement accuracy

= 1 % of the measuring range
Display accuracy

= 1 % of the measuring range
Product certifications

CULus
Standards

IEC 61000-6-4
IP degree of protection

IP65 conforming to IEC 60529, IP67 conforming to IEC 60529, IP69K conforming to DIN 40050
Vibration resistance

5 gn (f= 10-2000 Hz) conforming to IEC 60068-2-6
Shock resistance

25 gn conforming to IEC 60068-2-27
Electromagnetic compatibility

4 kV contact conforming to IEC 61000-4-2, electrical fast transient/burst immunity test: 2 kV conforming to IEC 61000-4-4, electrostatic discharge immunity test: 8 kV air, immunity to conducted RF disturbances: 10 V 0.15…80 MHz conforming to IEC 61000-4-6, surge immunity test: 1 kV conforming to IEC 61000-4-5, Susceptibility to electromagnetic fields: 10 V/m 80…2000 MHz conforming to IEC 61000-4-3
Unit type of package 1

PCE
Number of units in package 1

1
Package 1 height

4.9000 CENTIMETER
Package 1 width

9.1000 CENTIMETER
Package 1 length

4.3000 CENTIMETER
Package 1 weight

106.0000 GRAM
Unit type of package 2

S01
Package 2 height

15.0000 CENTIMETER
Package 2 width

15.0000 CENTIMETER
Package 2 length

40.0000 CENTIMETER
Package 2 weight

2.7070 KILOGRAM
Brand

Telemecanique
Description

Description

Telemecanique OsiSense XME Electronic Pressure Sensors

Enhance your industrial process efficiency with the Telemecanique OsiSense XME Electronic Pressure Sensors. Designed for accurate and reliable pressure monitoring, this device ensures precise measurements to optimize your operations. With a wide supply voltage range and low current consumption, it offers versatile integration into various systems.

  • Ensure seamless electrical connections with the female Connector M12 and male Connector M12 options.
  • Experience fast response times for both analog and discrete outputs, enhancing your system’s real-time monitoring capabilities.
  • Benefit from the durable construction and versatile mounting options, allowing for flexible installation in any position.

Trust in the certified quality and compliance with international standards, ensuring reliable performance in various industrial environments. Improve your process control with the Telemecanique OsiSense XME Electronic Pressure Sensors.
