Telemecanique XY2CJL17 Latching emergency stop rope pull switchXY2C - industify.com
Telemecanique

XY2CJL17 Telemecanique

SKU: XY2CJL17

Add to wishlist Add to compare
Categories: , Tag:
Product information
Product or component type

Latching emergency stop rope pull switch

Device short name

XY2C

Housing colour

Red RAL 3000

Overvoltage category

Class I conforming to EN/IEC 61140

Local signalling

Color indicator

Body Material

Zamak

Cover material

Galvanised steel

Reset

By pull button

Contacts type and composition

2 NC

Contact operation

Slow-break

Trigger cable anchor point

LH side

Connections - terminals

1 x 0.5…2 x 1.5 mm², Screw clamp terminal

Safety level

Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508

Safety reliability data

B10d = 500000 conforming to IEC 60947-5-5 value given for a life time of 20 years limited by mechanical or contact wear

Marking

CE

Positive opening

With conforming to EN/IEC 60947-5-1

Resistance across terminals

25 MOhm conforming to EN/IEC 60255-7 category 3, 25 mOhm conforming to NF C 93-050 method A

Terminals description ISO n°1

(11-22)NC

Compatibility code

XY2CJ

Standards

Work equipment directive 2009/104/EC

Product certifications

CCC, CSA, EAC, UL category NISD emergency stop devices

Protective treatment

TC

Vibration resistance

10 gn (f= 10-150 Hz) conforming to EN/IEC 60068-2-6

Shock resistance

50 gn 11 ms conforming to EN/IEC 60068-2-27

IP degree of protection

IP66 conforming to IEC 60529, IP67 conforming to IEC 60529

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

9.0000 CENTIMETER

Package 1 width

16.0000 CENTIMETER

Package 1 length

20.3000 CENTIMETER

Package 1 weight

810.0000 GRAM

Unit type of package 2

P06

Package 2 height

77.0000 CENTIMETER

Package 2 width

80.0000 CENTIMETER

Package 2 length

60.0000 CENTIMETER

Package 2 weight

53.0840 KILOGRAM

Unit type of package 3

S03

Package 3 height

30.0000 CENTIMETER

Package 3 width

30.0000 CENTIMETER

Package 3 length

40.0000 CENTIMETER

Package 3 weight

5.4960 KILOGRAM

Brand

Telemecanique

Description

Description

Telemecanique XY2CJL17 Emergency Stop Rope Pull Switch

Enhance Workplace Safety: The Telemecanique XY2CJL17 is a latching emergency stop rope pull switch designed to provide Class I safety conforming to EN/IEC standards, ensuring a reliable emergency stop solution for work equipment.

  • Color Indicator for Easy Identification
  • Positive Opening Feature for Added Protection
  • Resistance Across Terminals for Secure Operations

Durable Construction: With a body material of Zamak and galvanized steel cover material, this emergency stop switch offers a robust and long-lasting solution for industrial environments.

  • Protection against Vibration and Shock
  • IP66 and IP67 Degree of Protection for Harsh Conditions
