Name: XY2CE2A470 Telemecanique | Industify
Brand: Telemecanique
SKU: XY2CE2A470
Price: 1.00 USD
Availability: InStock

Product or component type

Latching emergency stop rope pull switch

Device short name

XY2CE

Housing colour

Red RAL 3000

Overvoltage category

class I conforming to NF C 20-030, Class I conforming to EN/IEC 61140

Local signalling

Without pilot light

Body Material

Zamak

Cover material

Stainless steel

Reset

By key-release push-button

Key number

421

Contacts type and composition

2 NC

Contact operation

Slow-break

Trigger cable anchor point

LH side

Connections - terminals

1 x 0.5…2 x 1.5 mm², Screw clamp terminal

Safety level

Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508

Safety reliability data

B10d = 300000 conforming to IEC 60947-5-5 value given for a life time of 20 years limited by mechanical or contact wear

Marking

Positive opening

With conforming to EN/IEC 60947-5-1

Resistance across terminals

25 MOhm conforming to EN/IEC 60255-7 category 3, 25 mOhm conforming to NF C 93-050 method A

Terminals description ISO n°1

(11-22)NC

Compatibility code

XY2CE

Standards

Work equipment directive 2009/104/EC

Product certifications

CCC, CSA, UL category NISD emergency stop devices

Protective treatment

Vibration resistance

10 gn (f= 10-300 Hz) conforming to EN/IEC 60068-2-6

Shock resistance

50 gn 11 ms conforming to EN/IEC 60068-2-27

IP degree of protection

IP65 conforming to IEC 60529

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

8.6000 CENTIMETER

Package 1 width

16.0000 CENTIMETER

Package 1 length

20.0000 CENTIMETER

Package 1 weight

1.6000 KILOGRAM

Unit type of package 2

S02

Package 2 height

15.0000 CENTIMETER

Package 2 width

30.0000 CENTIMETER

Package 2 length

40.0000 CENTIMETER

Package 2 weight

3.6450 KILOGRAM

Brand

Telemecanique

Description

Telemecanique XY2CE2A470 Emergency Stop Rope Pull Switch

Ensure Safety and Compliance: The Telemecanique XY2CE2A470 Emergency Stop Rope Pull Switch is designed to meet Class I standards, providing a reliable solution for emergency stop situations. With features such as slow-break contact operation and stainless steel composition, this switch offers durability and performance required for industrial applications.

Easy to Use and Install: The latching emergency stop design allows for quick activation in critical situations, while the LH side trigger cable anchor point ensures accessibility. The screw clamp terminals make installation straightforward, accommodating a range of wire sizes for flexibility in setups.

Enhanced Safety: Achieve peace of mind with a device that can reach category 4 safety levels when correctly installed and monitored, conforming to safety standards and reliability data.
Durable Construction: With a protective treatment, IP65 degree of protection, and resistance to vibrations and shocks, this emergency stop switch is built to withstand challenging industrial environments.
Compact and Efficient: The compact design and easy integration of the Telemecanique XY2CE2A470 make it a practical choice for enhancing safety protocols without compromising productivity.
