XS612B1PAL2 Telemecanique

Name: XS612B1PAL2 Telemecanique | Industify
Brand: Telemecanique
SKU: XS612B1PAL2
Price: 1.00 USD
Availability: InStock

SKU: XS612B1PAL2

Add to wishlist Add to compare

Categories: Inductive Sensors, Proximity Sensors, Sensors Tag: General purpose

Product information

Series name	General purpose
Sensor Type	Inductive proximity sensor
Sensor name	XS6
Device application	Mobile equipment
Sensor design	Cylindrical M12
Size	54 mm
Body type	Fixed
Type of output signal	Discrete
Wiring technique	3-wire
Discrete output function	1 NO
Detector flush mounting acceptance	Flush mountable
Discrete output type	PNP
material	Metal
Electrical connection	Cable
[Us] rated supply voltage	12…48 V DC with reverse polarity protection
Output circuit type	DC
Switching capacity in mA	= 200 mA DC with overload and short-circuit protection
IP degree of protection	IP68 double insulation conforming to IEC 60529, IP69K conforming to DIN 40050
Enclosure material	Nickel plated brass
Detection face	Frontal
Thread type	M12 x 1
Front material	PPS
Sensing range	> 2.5…4 mm
Differential travel	1…15 % of Sr
Cable composition	3 x 0.34 mm²
Status LED	output state: 1 LED (yellow)
Wire insulation material	PVC
Switching Frequency	= 2500 Hz
Voltage drop	2 V (closed)
Current consumption	= 10 mA no-load
Delay first up	10.0000 MILLISECOND
Delay response	0.2000 MILLISECOND
Marking	CE
Delay recovery	0.2000 MILLISECOND
Product certifications	E2
Vibration resistance	25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Shock resistance	50 gn for 11 ms conforming to IEC 60068-2-27
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.5000 CENTIMETER
Package 1 width	11.1000 CENTIMETER
Package 1 length	15.1000 CENTIMETER
Package 1 weight	78.0000 GRAM
Unit type of package 2	S03
Package 2 height	30.0000 CENTIMETER
Package 2 width	30.0000 CENTIMETER
Package 2 length	40.0000 CENTIMETER
Package 2 weight	4.2000 KILOGRAM
Unit type of package 3	P06
Package 3 height	75.0000 CENTIMETER
Package 3 width	60.0000 CENTIMETER
Package 3 length	80.0000 CENTIMETER
Package 3 weight	48.1120 KILOGRAM
Brand	Telemecanique

Description

Description

Description

Telemecanique XS612B1PAL2 General Purpose Inductive Proximity Sensor

Enhance Efficiency: The Telemecanique XS612B1PAL2 inductive proximity sensor offers reliable detection in mobile equipment applications, ensuring seamless operation and increased productivity for your system.

Durable Construction: With its IP68 double insulation and IP69K protection, this sensor is built to withstand harsh industrial environments, providing long-lasting performance and peace of mind in challenging conditions.

Easy Installation: The flush mountable design and compact size of the XS612B1PAL2 make it simple to integrate into your equipment, saving time and effort during setup.
Highly Sensitive: With a sensing range of over 2.5mm, this sensor offers precise detection capabilities, ensuring accurate and efficient operation in your application.
