Name: XS608B1NBL2 Telemecanique | Industify
Brand: Telemecanique
SKU: XS608B1NBL2
Price: 1.00 USD
Availability: InStock

Range of product

Telemecanique Inductive proximity sensors XS

Series name

General purpose

Sensor Type

Inductive proximity sensor

Sensor name

XS6

Sensor design

Cylindrical M8

Size

51 mm

Body type

Fixed

Type of output signal

Discrete

Wiring technique

3-wire

Discrete output function

1 NC

Detector flush mounting acceptance

Flush mountable

Discrete output type

NPN

material

Stainless steel

Electrical connection

Cable

[Us] rated supply voltage

12…24 V DC with reverse polarity protection

Output circuit type

Switching capacity in mA

= 200 mA DC with overload and short-circuit protection

IP degree of protection

IP67 conforming to IEC 60529

Enclosure material

Stainless steel 303

Detection face

Frontal

Thread type

M8 x 1

Front material

PPS

Sensing range

> 0…2.5 mm

Differential travel

1…15 % of Sr

Cable composition

3 x 0.11 mm²

Status LED

output state: 1 LED (yellow)

Wire insulation material

PVC

Switching Frequency

= 2500 Hz

Voltage drop

2 V (closed)

Current consumption

= 10 mA no-load

Delay first up

10.0000 MILLISECOND

Delay response

0.2000 MILLISECOND

Marking

Delay recovery

0.2000 MILLISECOND

Product certifications

Vibration resistance

25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6

Shock resistance

50 gn for 11 ms conforming to IEC 60068-2-27

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

1.7000 CENTIMETER

Package 1 width

14.7000 CENTIMETER

Package 1 length

20.4000 CENTIMETER

Package 1 weight

41.0000 GRAM

Unit type of package 2

S01

Package 2 height

15.0000 CENTIMETER

Package 2 width

15.0000 CENTIMETER

Package 2 length

40.0000 CENTIMETER

Package 2 weight

585.0000 GRAM

Brand

Telemecanique

Description

Telemecanique Inductive Proximity Sensor XS – Enhanced Performance and Reliability

Experience seamless operation: The Telemecanique Inductive Proximity Sensor XS offers a wide sensing range, ensuring accurate detection in various applications. Its compact size and flush mountable design provide flexibility for installation, enhancing overall user experience. With a durable stainless steel body and high IP degree of protection, this sensor guarantees reliability in harsh environments.

Ensure precise detection with a differential travel feature
Benefit from a robust design for vibration and shock resistance
Experience efficient wiring techniques for quick and easy installation

Efficient and Cost-Effective Solution: The Telemecanique Inductive Proximity Sensor XS operates with low current consumption and voltage drop, resulting in energy savings and minimal maintenance costs. Its status LED indicator offers visual feedback, enhancing user awareness and system control. This sensor’s certifications ensure compliance with industry standards, providing peace of mind for users.
