HomeShopProximity SensorsInductive SensorsXS212B4PAL2 Telemecanique
Telemecanique XS212B4PAL2 Telemecanique Inductive proximity sensors XSGeneral purpose - industify.com
Telemecanique

XS212B4PAL2 Telemecanique

SKU: XS212B4PAL2

Add to wishlist Add to compare
Categories: , , Tag:
Product information
Range of product

Telemecanique Inductive proximity sensors XS

Series name

General purpose

Sensor Type

Inductive proximity sensor

Sensor name

XS2

Device application

Mobile equipment

Sensor design

Cylindrical M12

Size

37 mm

Body type

Fixed

Type of output signal

Discrete

Wiring technique

3-wire

Discrete output function

1 NO

Detector flush mounting acceptance

Non flush mountable

Discrete output type

PNP

material

Metal

Electrical connection

Cable

[Us] rated supply voltage

12…24 V DC with reverse polarity protection

Output circuit type

DC

Switching capacity in mA

= 200 mA with overload and short-circuit protection

IP degree of protection

IP65 conforming to IEC 60529, IP67 conforming to DIN 40050, IP69K

Enclosure material

Nickel plated brass

Detection face

Frontal

Thread type

M12 x 1

Front material

PPS

Sensing range

> 4…8 mm

Differential travel

1…15 % of Sr

Cable composition

3 x 0.34 mm²

Status LED

output state: 1 LED (yellow)

Wire insulation material

PVC

Switching Frequency

= 2000 Hz

Voltage drop

2 V (closed)

Current consumption

= 10 mA no-load

Delay first up

15.0000 MILLISECOND

Delay response

0.2000 MILLISECOND

Marking

CE

Delay recovery

0.2000 MILLISECOND

Product certifications

E2

Vibration resistance

25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6

Shock resistance

50 gn for 11 ms conforming to IEC 60068-2-27

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

13.4600 CENTIMETER

Package 1 width

10.1600 CENTIMETER

Package 1 length

5.0800 CENTIMETER

Package 1 weight

0.0900 KILOGRAM

Unit type of package 2

S02

Package 2 height

15.0000 CENTIMETER

Package 2 width

30.0000 CENTIMETER

Package 2 length

40.0000 CENTIMETER

Package 2 weight

2.4130 KILOGRAM

Unit type of package 3

PAL

Package 3 height

60.0000 CENTIMETER

Package 3 width

80.0000 CENTIMETER

Package 3 length

77.0000 CENTIMETER

Package 3 weight

31.3280 KILOGRAM

Brand

Telemecanique

Description

Description

Telemecanique Inductive Proximity Sensor XS: Enhancing Efficiency and Precision

The Telemecanique Inductive Proximity Sensor XS is designed to boost operational efficiency and ensure precision in industrial applications. With a robust yet compact body type and nickel-plated brass material, this sensor offers durability and reliability in various working environments. The sensor’s high switching capacity and precise sensing range enable accurate detection of objects, contributing to seamless automation processes.

  • Enhanced Performance: The sensor’s detecting face and flush mounting acceptance allow for swift and efficient detection, minimizing downtime and optimizing workflow.
  • Diverse Applications: Ideal for mobile equipment and industrial machinery, the XS sensor series caters to a wide range of applications, ensuring versatility and adaptability in different settings.
  • Easy Installation: With user-friendly wiring techniques and clear indicator LEDs, the sensor simplifies installation and maintenance, streamlining processes for increased productivity.
