Name: XMLA010A2S11 Telemecanique | Industify
Brand: Telemecanique
SKU: XMLA010A2S11
Price: 1.00 USD
Availability: InStock

Product or component type

Electromechanical pressure sensor

Pressure sensor type

Electromechanical pressure sensor

Device short name

XMLA

Controlled fluid

Air (0-70 °C), Fresh water (0-70 °C), hydraulic oil (0-70 °C)

Fluid connection type

G 1/4 (female) conforming to ISO 228

Electrical connection

1 connector Pg 13, 1 x 0.5…2 x 2.5 mm², Screw-clamps terminals

AWG gauge

AWG 20…AWG 14

Cable entry

Cable gland 9-13 mm

Contacts type and composition

1 C/O

Product specific application

Not applicable

Pressure switch type of operation

Detection of 1 single threshold

Electrical circuit type

Control circuit

Scale type

Fixed differential

Local display

With

Pressure actuator

Diaphragm

Materials in contact with fluid

FKM, FPM

Enclosure material

Zinc alloy

Terminal block type

4 terminals

Operating rate

120 cyc/mn

Auxiliary contacts operation

Snap action

Contacts material

Silver contacts

Resistance across terminals

25 mOhm conforming to IEC 255-7 category 3, 25 mOhm conforming to NF C 93-050 method A

Setting

External

Standards

IEC 60947-5-1

Product certifications

LROS (Lloyds register of shipping)

Protective treatment

TC standard version

Operating position

Any position

Vibration resistance

4 gn conforming to IEC 60068-2-6 (f = 30-500 Hz)

Shock resistance

50 gn conforming to IEC 60068-2-27

Electrical shock protection class

Class I conforming to IEC 1140, Class I conforming to IEC 536, class I conforming to NF C 20-030

IP degree of protection

IP66 conforming to IEC 60529

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

4.0000 CENTIMETER

Package 1 width

12.1000 CENTIMETER

Package 1 length

8.6000 CENTIMETER

Package 1 weight

700.0000 GRAM

Unit type of package 2

S02

Package 2 height

15.0000 CENTIMETER

Package 2 width

30.0000 CENTIMETER

Package 2 length

40.0000 CENTIMETER

Package 2 weight

9.5080 KILOGRAM

Brand

Telemecanique

Description

Telemecanique Electromechanical Pressure Sensor

Enhance Your Control System Efficiency: The Telemecanique Electromechanical Pressure Sensor is designed to provide precise control and monitoring of pressure levels in various fluids, including air, water, and hydraulic oil. With a reliable diaphragm and durable materials in contact with the fluid, this sensor ensures accurate detection and operation in a range of applications.

Easy Installation and Versatile Usage: Featuring a snap-action mechanism and simple cable connections, this pressure sensor offers hassle-free installation and compatibility with different electrical circuits. The user-friendly design, along with a local display for easy monitoring, makes it suitable for a wide range of industrial settings where pressure control is critical.

Efficient Control Circuits: Ensure precise pressure control with fixed differential and single threshold detection.
Durable Construction: Built with high-quality materials and a zinc alloy enclosure, this sensor offers long-term reliability in demanding environments.
Multiple Certifications: Compliant with industry standards and certifications like IEC and LROS, ensuring quality and performance in various applications.
