XCSDMR7902 Telemecanique

Name: XCSDMR7902 Telemecanique | Industify
Brand: Telemecanique
SKU: XCSDMR7902
Price: 1.00 USD
Availability: InStock

SKU: XCSDMR7902

Add to wishlist Add to compare

Categories: Magnetic Safety Switch, Safety Equipment, Safety Switches Tag: Telemecanique Safety switches XCS

Product information

Range of product	Telemecanique Safety switches XCS
Product or component type	Coded magnetic switch
Component name	XCSDMR
Design	Cylindrical
Size	Ø 30 x 38.5 mm
Contacts type and composition	2 NC
Contact operation	staggered
material	Plastic
Electrical connection	Pre-cabled
Cable composition	4 x 0.25 mm²
Approach directions	1 direction
[Ue] rated operational voltage	24 V DC
[Ie] rated operational current	100.0000 MILLIAMPERE
Contacts material	Rhodium
Switching capacity in mA	0.1…100 mA
Insulation resistance	1000 MOhm
Switching Frequency	150 Hz
Safety level	Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508
Safety reliability data	B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear
Enclosure material	Thermoplastic PBT
Cable material	PVC
Standards	IEC 60204-1
Product certifications	UL
Protective treatment	TH
Vibration resistance	10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6
Shock resistance	30 gn for 11 ms conforming to IEC 60068-2-27
Sensitivity to magnetic fields	0.3000 MILLITESLA
Electrical shock protection class	Class II conforming to IEC 61140
IP degree of protection	IP66 conforming to IEC 60529, IP67 conforming to IEC 60529
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	3.5000 CENTIMETER
Package 1 width	13.5000 CENTIMETER
Package 1 length	15.5000 CENTIMETER
Package 1 weight	160.0000 GRAM
Unit type of package 2	S02
Package 2 height	15.0000 CENTIMETER
Package 2 width	30.0000 CENTIMETER
Package 2 length	40.0000 CENTIMETER
Package 2 weight	3.4350 KILOGRAM
Brand	Telemecanique

Description

Description

Description

Telemecanique Safety Switches XCSCoded Magnetic Switch

Enhance Safety: The Telemecanique Safety Switch XCSDMR features a coded magnetic design that ensures reliable and secure operation, providing peace of mind in various applications.

Durable Construction: With a robust plastic composition and high-quality contacts, this safety switch is built to last, offering long-term reliability and consistent performance in challenging environments.

Easy Installation: Pre-cabled for convenience, this cylindrical switch is simple to set up and integrate into existing systems, saving time and effort during installation and maintenance tasks.
