XCSDMR590L01M12 Telemecanique

Name: XCSDMR590L01M12 Telemecanique | Industify
Brand: Telemecanique
SKU: XCSDMR590L01M12
Price: 1.00 USD
Availability: InStock

SKU: XCSDMR590L01M12

Add to wishlist Add to compare

Categories: Magnetic Safety Switch, Safety Equipment, Safety Switches Tag: Coded magnetic switch

Product information

Product or component type	Coded magnetic switch
Component name	XCSDMR
Design	Cylindrical
Size	Ø 30 x 38.5 mm
Contacts type and composition	1 NC + 1 NO
Contact operation	staggered
material	Plastic
Electrical connection	Connector on flying lead
Connector type	M12
Approach directions	1 direction
[Ue] rated operational voltage	24 V DC
[Ie] rated operational current	100.0000 MILLIAMPERE
Contacts material	Rhodium
Switching capacity in mA	0.1…100 mA
Insulation resistance	1000 MOhm
Switching Frequency	150 Hz
Safety level	Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508
Safety reliability data	B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear
Enclosure material	Thermoplastic PBT
Cable material	PVC
Standards	IEC 60204-1
Product certifications	UL
Protective treatment	TH
Vibration resistance	10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6
Shock resistance	30 gn for 11 ms conforming to IEC 60068-2-27
Sensitivity to magnetic fields	0.3000 MILLITESLA
Electrical shock protection class	Class II conforming to IEC 61140
IP degree of protection	IP67 conforming to IEC 60529
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	3.5000 CENTIMETER
Package 1 width	15.0000 CENTIMETER
Package 1 length	17.0000 CENTIMETER
Package 1 weight	96.0000 GRAM
Unit type of package 2	S02
Package 2 height	15.0000 CENTIMETER
Package 2 width	30.0000 CENTIMETER
Package 2 length	40.0000 CENTIMETER
Package 2 weight	4.2040 KILOGRAM
Brand	Telemecanique

Description

Description

Description

Telemecanique XCSDMR590L01M12 Coded Magnetic Switch

Enhance Safety: The Telemecanique XCSDMR590L01M12 Coded Magnetic Switch is designed to deliver reliable safety performance, reaching category 4 with the appropriate monitoring system in place. With SIL 3 capabilities, this switch ensures high safety reliability data for peace of mind.

Durable Construction: Made with quality materials including thermoPlastic and PVC, this switch offers superior vibration and shock resistance, ensuring longevity and consistent performance even in demanding environments.

Easy Installation: The cylindrical design and compact size of Ø 30 x 38.5 mm make it easy to install in various applications, providing a user-friendly experience.
Waterproof Protection: With an IP67 degree of protection, this switch is suitable for use in wet or dusty conditions.
