HomeShopSafety SwitchesMechanic Safety SwitchXCSD3718P20 Telemecanique
Telemecanique XCSD3718P20 Telemecanique Safety switches XCSSafety limit switch - industify.com
Telemecanique

XCSD3718P20 Telemecanique

SKU: XCSD3718P20

Add to wishlist Add to compare
Categories: , , Tag:
Product information
Range of product

Telemecanique Safety switches XCS

Product or component type

Safety limit switch

Component name

XCSD

Design

Compact

material

Metal

Head type

Rotary head

Protection technology

Plastic protective cover, secured by 5-lobe socket head safety screw

Type of operator

Thermoplastic roller lever

Contact operation

break before make, Slow-break

Contacts type and composition

1 NC + 1 NC + 1 NO

Cable entry

1 entry tapped for M20 x 1.5

Electrical connection

Terminal

Clamping connection capacity

1 x 0.34…2 x 0.75 mm²

Positive opening

With NC contact

Switch actuation

By 30° cam

Contact code designation

R300, AC-15 (Ue = 240 V, B300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix A, Ie = 1.5 A) conforming to EN/IEC 60947-5-1 appendix A

Resistance across terminals

25 MOhm conforming to IEC 60255-7 category 3

Repeat accuracy

0.1 mm on tripping points, 1 million operating cycles for head with end plunger

Enclosure material

Plastic

Safety level

can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508, Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1

Body Material

Zamak

Head material

Zamak

Safety reliability data

B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear

Protective treatment

TC

Product certifications

UL

Electrical shock protection class

class I conforming to NF C 20-030

Standards

EN/IEC 60204-1

Vibration resistance

25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6

Shock resistance

50 gn for 11 ms conforming to IEC 60068-2-27

IK degree of protection

IK06 conforming to EN 50102

IP degree of protection

IP66 conforming to IEC 60529, IP67 conforming to IEC 60529

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

13.2000 CENTIMETER

Package 1 width

3.4000 CENTIMETER

Package 1 length

5.0000 CENTIMETER

Package 1 weight

241.0000 GRAM

Unit type of package 2

S01

Package 2 height

15.0000 CENTIMETER

Package 2 width

15.0000 CENTIMETER

Package 2 length

40.0000 CENTIMETER

Package 2 weight

1.7190 KILOGRAM

Brand

Telemecanique

Description

Description

Telemecanique Safety Switch XCSD3718P20

The Telemecanique Safety Switch XCSD3718P20 offers reliable protection for industrial applications, ensuring safe operation and preventing accidents. With its compact design and metal construction, this safety limit switch from Telemecanique is built to withstand tough environments while providing accurate performance and consistent operation.

  • Ensures safe operation in industrial settings
  • Compact design and metal construction for durability
  • Prevents accidents and ensures reliable performance

The XCSD3718P20 features a rotary head and plastic protective cover secured by a 5-lobe socket head safety screw, offering ease of use and added protection. With an IP66/67 degree of protection, this safety switch is suitable for a wide range of applications, providing peace of mind in demanding environments.

  • Rotary head and plastic protective cover for user convenience
  • IP66/67 degree of protection for versatile use
  • Adds peace of mind in demanding industrial environments
