HomeShopPLCs (Programmable Logic Controllers)Communication ModulesNR-EN16 Keyence Multi-input Data Logger
Keyence NR-EN16 [urunkategori] - industify.com
Keyence

NR-EN16 Keyence Multi-input Data Logger

(1 customer review)

Add to wishlist Add to compare
Categories: , , , Tag:
Product information
Model

NR-EN16

Connection target devices

CL-3000 Series, DL-EN1 (Connected sensor: GT2 Series, FD-EC Series, FD-EP Series, FD-G Series, FD-H Series, FD-R Series, FD-X Series, FI-1000, FI-T Series)*1;LK-G5000 Series, FL Series, GP-M Series, GT Series, IB Series, IG Series, IL Series, IX Series, LJ-V7000 Series, LJ‑X8000 Series, LR-T Series, LS-9000 Series;Connection of one of the above devices per NR-EN16 allowed, SK Series)*1NQ-EP4L (Connected sensor: FD-Q Series

Connection target device identification

Automatic identification or manual identification by specifying the IP address

Communication protocols

BOOTP/DHCP client supported (compatible with the above connection target devices), Ethernet TCP/UDP communication

Interface

1 port*2, Ethernet 100Base-TX (AUTO-MDI/MDIX-compatible)

Number of channels

16 ch max. (varies depending on connected devices)

Collection period

Maximum sampling cycle: 1 ms (1 kHz) to 60 sWith effective rate display function for communication between connected sensors*3

Buffer memory

8M data*4

Sensor power output function

• Output from power supply output connector (4-pole terminal block) (switchable between output ON and OFF)• Output voltage: 24 VDC ±10%• Rated current: Max. 0.6 A (switchable between 0.3 A and 0.6 A)•, switchable between 0.35 A (typ.) and 0.70 A (typ.) protection current• Class 2 power supply (CSA C22.2 No. 223 / UL 1310 compliant)• Sensor power supply not insulated from system bus

Power consumption

1.6 W or less*5

Surrounding air temperature

0 to +40°C 32°F to 104°F

Operating ambient humidity

10 to 85% RH (no condensation)

Weight

Approx. 150 g 5.30 oz (including approx. 10 g 0.35 oz for the OP-88513 (NR-EN16 power supply terminal block))

Brand

Keyence

Description

Keyence NR-EN16 Multi-input Data Logger

Enhance data collection efficiency with the Keyence NR-EN16 Multi-input Data Logger. This device allows for seamless connection with a wide range of sensors, enabling automatic identification and communication with various target devices. With Ethernet TCP/UDP communication and support for up to 16 channels, users can easily manage data from different sources in real-time.

Maximize productivity and accuracy by utilizing the 8MB buffer memory and sensor power output function of the NR-EN16. With a collection period ranging from 1 ms to 60 s, users can customize sampling cycles to meet their specific requirements. The compact and lightweight design, coupled with low power consumption, makes this data logger ideal for various industrial environments.

  • Efficient data collection and management
  • Customizable sampling cycles for precise monitoring
  • Seamless connectivity with multiple sensors and devices
