NF125-SGV 3P 70-100A – 254915 Mitsubishi Molded Case Circuit Breaker

Name: NF125-SGV 3P 70-100A - 254915 Mitsubishi Molded Case Circuit Breaker | Industify
Brand: Mitsubishi Electric
SKU: NF125-SGV 3P 70-100A
Price: 1.00 USD
Availability: InStock

SKU: NF125-SGV 3P 70-100A

Add to wishlist Add to compare

Categories: Circuit Breakers, Circuit Breakers and Electrical Protection, Molded Case Circuit Breakers Tags: 254915, NF125-SGV 3P 70-100A

Product information

Series	WS-V SERIES – MCCB
Type	NF-S TYPE (STANDARD CLASS)
Frame Size	125
Rated Current (A)	70-100
Current Type	AC/DC
Number of Poles	3
Rated Voltage (V)	690
Breaking Capacity at 400V (kA)	36/36
Compliant with Standard(s)	EN 60947-2, IEC 60947-2
Cycles with Rated Current	30000
Cycles without Rated Current	50000
Automatic Tripping Device	THERMAL-MAGNETIC
Depth (mm)	92
Weight (kg)	6, 1
Width (mm)	105
Height (mm)	165
CE	COMPLIANT
Shipping Approvals	ABS, BV, CCS, DNV·GL, LR
EAC	NON-COMPLIANT
UL/cUL	NON-COMPLIANT
UKCA	COMPLIANT
Cardboard (g)	97
REACH Limit Exceeded	NO
RoHS Compliance	COMPLIANT
Dangerous Goods Class	NO
WEEE	B2B
Dangerous Goods Identifier	NO
Brand	Mitsubishi Electric

Description

Description

Mitsubishi NF125-SGV 3P 70-100A Moulded-Case Circuit Breaker

Experience reliable and efficient electrical protection with the Mitsubishi NF125-SGV Moulded-Case Circuit Breaker. This MCCB from the WS-V SERIES offers a robust solution for your electrical system, ensuring safe operation and peace of mind for users. With a high breaking capacity at 400V and compliance with industry standards, this circuit breaker is designed to protect your equipment and prevent electrical hazards.

Ensures reliable electrical protection
Compliant with industry standards for safety
High breaking capacity at 400V for efficient operation
Designed for robust and safe performance

The Mitsubishi NF125-SGV MCCB is the ideal choice for applications where reliable electrical protection is essential. Trust in Mitsubishi’s quality and innovation to safeguard your electrical systems and equipment.
