G3PE-235B 12-24VDC Omron

Name: G3PE-235B 12-24VDC Omron | Industify
Brand: Omron
SKU: G3PE-235B 12-24VDC
Price: 1.00 USD
Availability: InStock

SKU: G3PE-235B 12-24VDC

Add to wishlist Add to compare

Categories: Circuit Breakers and Electrical Protection, Solid-State Relays (SSR) Tags: G3PE-235B 12-24VDC, Omron

Product information

Application	ON/OFF control
Number of phases	1
Number of Poles	1
Mounting Method	DIN rail/screw
Terminal	Screw
Complete with socket	No
LED indicator	Yes
Rated operational voltage, AC	100-240 V
Operating voltage range, AC	75-264 V
Rated operation current Ie at AC-1	35 A
Permissible I²t value	1260 A²s
Applicable heater capacity (AC1: resistive load)	7 kW
Product Height (unpacked)	100 mm
Product Width (unpacked)	44.5 mm
Product Depth (unpacked)	100 mm
Supply Voltage DC	12-24 V
Control current max.	10 mA
Must operate voltage max.	9.6 V
Must release voltage min.	1 V
Maximum operating temperature	80 °C
Minimum operating temperature	-30 °C
Isolation	Phototriac
Switching at zero-crossing	Yes
Brand	Omron

Description

Description

Description

Omron G3PE-235B 12-24VDC Solid State Relay

Experience reliable control over your electrical systems with the Omron G3PE-235B Solid State Relay. This advanced device offers ON/OFF control for enhanced efficiency and accuracy in your operations. Its wide operating voltage range ensures compatibility with various setups, while the built-in LED indicator allows for quick status checks at a glance.

Achieve precise temperature control with the G3PE-235B’s high applicable heater capacity of 7 kW
Ensure smooth operation with the switching at zero-crossing feature
Benefit from its compact and easy-to-install design for seamless integration into your system

Trust in the Omron G3PE-235B Solid State Relay for dependable performance and peace of mind in your industrial applications. Enhance your control systems with this reliable solution from a trusted brand.
