Telemecanique 9016GVG1J09E Electromechanical vacuum switchPower circuit application - industify.com
Telemecanique

9016GVG1J09E Telemecanique

SKU: 9016GVG1J09E

Add to wishlist Add to compare
Categories: , , Tag:
Product information
Product or component type

Electromechanical vacuum switch

Device application

Power circuit application

Device short name

9016GVG

Electrical circuit type

Power circuit

Factory modification

3-way lever

Vacuum switch type of operation

Regulation between two thresholds

Scale type

Adjustable

Value of setting

3…8 inHg

Maximum pressure

100 psi

Local display

Without

Fluid connection type

0.25 inch 18 NPSF conforming to UL 508

Electrical connection

Screw-clamp terminals AWG 22…AWG 12

Terminal block type

8 screw terminals

Pressure actuator

Diaphragm nitrile (Buna-N)

Controlled fluid

air (-40-250 °F), Hydraulic oil (-40-250 °F), gas (-40-250 °F), water (-40-250 °F)

Materials in contact with fluid

3M Scotch-Grip 847 rubber and gasket adhesive

Cover material

noryl thermoplastic resin or equivalent, Polypropylene

Operating position

Any position

Enclosure material

Stamped metal

Operating rate

100 cyc/mn

Repeat accuracy

0.025

Contacts type and composition

2 NC, DPST-DB, Form YY, silver cadmium contacts, snap action

Setting

Internal

Standards

UL 508

Product certifications

UL listed

Protective treatment

None

NEMA degree of protection

NEMA 1 conforming to UL 698

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

75.0320 CENTIMETER

Package 1 width

29.5400 CENTIMETER

Package 1 length

190.5820 CENTIMETER

Package 1 weight

2.0870 KILOGRAM

Brand

Telemecanique

Description

Description

Telemecanique Electromechanical Vacuum Switch

The Telemecanique Electromechanical Vacuum Switch delivers precise regulation between two thresholds, ensuring optimal performance in power circuit applications. With an adjustable setting ranging from 3 – 8 inHg and a maximum pressure of 100 psi, this device offers flexibility and reliability in various operating conditions. The nitrile diaphragm and durable materials in contact with fluids guarantee long-lasting use across a wide temperature range.

  • Accurate Regulation: Regulate between two thresholds with precision for consistent performance.
  • Flexible Setting: Adjust the switch setting from 3 – 8 inHg to suit specific pressure requirements.
  • Durable Construction: Constructed with high-quality materials for reliable operation in diverse fluid applications.
