Name: 9016GVG1J09 Telemecanique | Industify
Brand: Telemecanique
SKU: 9016GVG1J09
Price: 1.00 USD
Availability: InStock

Range of product

9016GVG

Product or component type

Electromechanical vacuum switch

Device application

Power circuit application

Device short name

9016GVG

Electrical circuit type

Power circuit

Factory modification

Not applicable

Vacuum switch type of operation

Regulation between two thresholds

Scale type

Adjustable

Value of setting

3…8 inHg

Maximum pressure

100 psi

Local display

Without

Fluid connection type

0.25 inch 18 NPSF conforming to UL 508

Electrical connection

Screw-clamp terminals AWG 22…AWG 12

Terminal block type

8 screw terminals

Pressure actuator

Diaphragm nitrile (Buna-N)

Controlled fluid

air (-40-250 °F), Hydraulic oil (-40-250 °F), gas (-40-250 °F), water (-40-250 °F)

Materials in contact with fluid

3M Scotch-Grip 847 rubber and gasket adhesive

Cover material

noryl thermoplastic resin or equivalent, Polypropylene

Operating position

Any position

Enclosure material

Stamped metal

Operating rate

100 cyc/mn

Repeat accuracy

0.025

Contacts type and composition

2 NC, DPST-DB, Form YY, silver cadmium contacts, snap action

Setting

Internal

Standards

UL 508

Product certifications

UL listed

Protective treatment

None

NEMA degree of protection

NEMA 1 conforming to UL 698

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

13.5000 CENTIMETER

Package 1 width

12.2000 CENTIMETER

Package 1 length

20.1000 CENTIMETER

Package 1 weight

1.5600 KILOGRAM

Brand

Telemecanique

Description

Telemecanique Electromechanical Vacuum Switch – SKU: 9016GVG1J09

The Telemecanique Electromechanical Vacuum Switch offers precise regulation between two thresholds, providing adjustable settings to suit varying needs. With a maximum pressure of 100 psi and a range of applications including air, water, hydraulic oil, and gas, this switch ensures reliable performance across different fluid types and temperatures. The snap action contacts with silver cadmium ensure repeat accuracy, enhancing system control and efficiency.

Provides adjustable settings for precise regulation
Offers reliable performance across various fluid types and temperatures
Ensures repeat accuracy with snap action contacts

The Telemecanique Electromechanical Vacuum Switch is UL listed and meets NEMA 1 standards for added protection. The polypropylene and noryl construction with rubber and gasket adhesive materials provide durability while the compact size allows for flexible installation in different systems. Whether for industrial or commercial applications, this vacuum switch offers reliable performance and easy integration for enhanced system control.
