Telemecanique 9007TUC1 Severe dutyUniversal mill switch - industify.com

9007TUC1 Telemecanique

Name: 9007TUC1 Telemecanique | Industify
Brand: Telemecanique
SKU: 9007TUC1
Price: 1.00 USD
Availability: InStock

SKU: 9007TUC1

Add to wishlist Add to compare

Categories: Limit Switches, Mechanical Limit Switches, Replacement Parts for Sensors, Spare Parts and Accessories, Switches and Actuators Tag: Severe duty

Product information

Series name	Severe duty
Device application	Universal mill switch
Device short name	T
Head type	Rotary head
Base plate style	Style C
Body Material	Cast zinc
Switch actuation	CW
Electrical connection	Screw clamp terminal AWG 22…AWG 12
Cable entry	cable outer diameter: 0.5-0.5 in conforming to UL 508, NPT conduit entry
Switch function	SPDT-DB
Contact operation	Snap action
Contact form	Form Z
Contacts material	Silver flashed copper
Contact status	Closed A for CCW position, closed B for CW position, open A for CW position, open B for CCW position
Positive opening	Without
Type of operator	spring return, Spring return lever arm to be ordered separately
Repeat accuracy	+/- 0.004 in 0.1 mm
Contact code designation	A600, Q600
Product certifications	UL listed
Shock resistance	30 gn
Vibration resistance	10 gn (f= 10-55 Hz)
NEMA degree of protection	NEMA 1/2/4/12/13
IP degree of protection	IP65, IP66, IP67
Electrical shock protection class	Class 0
Protective treatment	Corrosion resistant gray paint
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	16.2000 CENTIMETER
Package 1 width	16.2000 CENTIMETER
Unit type of package 2	S02
Package 1 length	16.2000 CENTIMETER
Package 1 weight	1.1260 KILOGRAM
Package 2 height	15.0000 CENTIMETER
Package 2 width	30.0000 CENTIMETER
Package 2 length	40.0000 CENTIMETER
Package 2 weight	7.0660 KILOGRAM
Brand	Telemecanique

Description

Description

Description

Enhance Your Control System with the Telemecanique Severe Duty Universal Mill Switch

Experience seamless and reliable operation with Telemecanique’s Severe Duty Universal Mill Switch. This durable switch features a corrosion-resistant gray paint and a spring return lever arm option for added convenience. With a positive opening and repeat accuracy of +/- 0.004 inches, you can trust in precise control and consistent performance.

Benefit from the UL listed certification for enhanced safety and quality assurance.
With NEMA 1/2/4/12/13 and IP degree of protection 65, 66, and 67, this switch is suitable for a variety of environments.
The cast zinc body and snap action contact operation ensure durability and reliability in severe duty applications.
